LEGRAND DX³10000 16kA circuit breaker, top inlet and bottom outlet, screw type, 4P - 400V~ - 80A - curve C - 6 modules

Ref. 4 093 62 Product Features DX³ four-pole circuit breaker 400V~ breaking capacity: - 10000A compliant with standard NF EN 60891-1 for residential installations - 16kA compliant with standard EN 60947-2 Departure protection: high inlet and low outlet via screw terminals Nominal intensity 80A - Curve C (magnetic triggering 7In +/- 20%) - 6 modules For traditional wiring Receives DX³ auxiliaries and accessories and accepts adaptable differential blocks - IP20 touch-protected terminals, wired device The + installation Equipped with 2 hooking claws, allowing the circuit breaker to be replaced in the middle of a combed row without disconnecting the other products The advantages of use Equipped with a label holder for quick and easy visual identification of the protected circuit - Immediate visual indication of the ON and OFF status on the lever in green and red Recommendations / restrictions on use Not paintable Range Information By successfully combining high breaking capacity, high nominal current and small footprint, DX³ modular circuit breakers perfectly meet the constraints of selectivity and space saving, while ensuring optimal protection of people and property defined by the NF C 15-100 standard. They prevent the entire installation from being shut down in the event of a fault and reinforce the breaking capacity of the downstream protection. They can be installed in residential, small tertiary and large tertiary construction sites with breaking capacities from 6 kA to 50 kA. The DX³ STOP ARC circuit breaker is a new Legrand product, which limits the risk of fire caused by electric arc faults. The DX³ range also includes residual current circuit breakers, residual current switches as well as auxiliaries that ensure remote tripping of circuit breakers, and adaptable residual current devices.
